Before You Start
Install sintered stone by preparing a stable, flat base, dry-fitting the layout, using the approved bonding or support system, preserving movement joints, and checking the installation before it is put into service. Floors and bonded walls need verified adhesive contact; countertops also need a support plan around seams, sinks, appliance openings and overhangs.
Start with the slab’s current installation instructions and the selected adhesive or fixing system. The sequence below shows what to check at each stage, with separate routes for floors, countertops, walls and outdoor work.
1. Match the Slab to the Installation System
A thickness suitable for a backed wall panel does not automatically work as an unsupported worktop or raised paver. Specify the application, finished panel size, slab thickness, backing, exposure and expected load together.
| Application | What carries the slab | What to verify before installation |
|---|---|---|
| Interior floor | Prepared substrate and an approved, continuously bedded adhesive system | Floor-rated slab, substrate movement, finish for the use zone, joints and time to traffic |
| Interior or shower wall | Load-rated wall assembly and compatible bonding system | Board or render capacity, backing compatibility, waterproofing and temporary support |
| Countertop or island | Level cabinetry, rails or a designed frame, with the specified bonding arrangement | Cutouts, sink cradle, supported seams, appliance bays and overhangs |
| Exterior paving or facade | A designed bonded, supported or mechanically fixed assembly | Product approval, drainage, loads, wind restraint, fixings and movement |
Funtek’s current fabrication manual lists 6 and 9 mm slabs with continuous backing or support, 12 and 15 mm worktop options, and 20 mm custom production requiring a support plan. Use the Funtek fabrication and installation manual to check the exact thickness and geometry. Do not treat a generic “20 mm outdoor slab” label as approval for a pedestal deck or driveway.
Before selecting flooring for installation, confirm use zones, finishes, formats and the information needed for a supply enquiry.
2. Prepare the Site, Tools and Handling Route
Inspect the delivered slabs before cutting: photograph chips, cracks, damaged corners, labels and any mesh or resin backing. Match the face direction and batch to the layout. Keep damaged pieces aside until the supplier and fabricator have assessed them.
The installer needs a straightedge and measuring tools, a stable cutting table, equipment approved for the slab, rated suction lifters or a lifting frame, the specified trowels and bedding tools, mixing equipment, spacers, and joint-cleaning tools. Check the access route through doors, stairs and lifts before releasing large finished parts. Obtain the actual slab mass or use the slab weight calculator when planning handling equipment.
Check flatness, stability and moisture separately
Lay a straightedge across the substrate in several directions and mark high spots and depressions. A base may be level overall while still having local bumps that prevent a large slab from bedding evenly. Correct these areas before spreading the setting adhesive.
For a numerical example, LATICRETE TDS 170F specifies maximum variation of 3 mm in 3 m and 1.6 mm in 600 mm for its gauged porcelain floor-panel installations. Check the complete substrate requirements and use the tolerance approved for your slab and assembly; a cabinet support plan needs its own bearing checks.

Remove loose material and bond-breaking contamination. Investigate cracks and moving joints, test moisture by the method required for the substrate and adhesive, and complete any specified repairs, primer or membrane. An adhesive bed cannot make an unstable subfloor structurally adequate.
Control dust before any cutting starts
Cutting or grinding silica-containing slabs can release hazardous respirable dust. Read the exact product SDS, plan fabrication off site where practical, and use the required water-fed tools, extraction and work-area controls. Keep slurry from drying into dust; use wet cleaning or suitable HEPA vacuuming instead of dry sweeping.
The OSHA/NIOSH countertop fabrication alert explains that respirator selection depends on exposure and the applicable respiratory-protection programme. Water suppression alone does not prove exposure is controlled. The sintered stone silica guide explains how to check material documentation.
3. Install Sintered Stone Flooring Step by Step
For bonded floors, the working sequence is substrate acceptance, dry layout, adhesive mixing, spreading, placement, contact checks and protection. Complete the first panel as a trial so the installer can adjust the method before repeating it across the floor.

Step 1: Dry-lay the pattern and mark joints
Check the starting line, doorway transitions, perimeter gaps, drain positions and vein direction. Plan cuts before mixing adhesive. Carry the building’s movement joints through the finish in the approved detail, and avoid a layout that leaves fragile narrow strips around openings.
Step 2: Select and mix a compatible adhesive
Choose an adhesive whose current data sheet covers the slab format, substrate, backing, wet or dry exposure and any floor heating. C2 identifies an improved cementitious adhesive class; S1 and S2 describe deformability. These classifications help shortlist a product, but do not by themselves approve every large slab or backing.
For example, Niro Granite specifies C2TES2 for its Zirconio system. Treat that as a named system requirement. For a Funtek project, have the adhesive supplier confirm compatibility with the selected Funtek slab and its actual reverse surface.
Measure mixing water, observe mixing and rest times, and keep each batch within the product’s pot life. Do not add extra water to revive mortar that has begun setting.
Step 3: Spread adhesive on the base and slab back
Use the approved trowel and back-buttering method. Where both surfaces are notched, comb straight ridges in matching directions so air can escape during bedding; avoid closed circles and isolated adhesive spots. Some panel systems require a flat skim coat on the back instead, so check the panel instructions.
Laminam’s cladding and flooring guide illustrates full-spread double coating, with aligned ridges parallel to the short side and particular attention to edges and corners. Spread only the area that can be covered within the adhesive’s open time.

Step 4: Place and bed the slab
Lower the panel with the rated handling equipment without dragging its corners. Use the bedding motion and tools specified for the slab to collapse the adhesive ridges. Keep joint spacing consistent. Levelling clips can assist edge alignment, but must not be used to pull a slab across a hollow or bend it against an uneven base.
Step 5: Check adhesive transfer while the bed is workable
Lift a representative newly placed panel using the approved handling method and inspect the transfer on both surfaces. Look for uncollapsed ridges, dry areas, edge voids and mortar that has skinned over. If contact is inadequate, stop and correct the spread area, trowel, mortar condition or bedding technique before continuing.

Do not use a single coverage percentage as the acceptance rule for every sintered-stone installation. LATICRETE’s gauged-panel guidance combines a coverage threshold with void-size and edge-support requirements, while Laminam specifies full-spread contact. Apply the complete requirement for the selected product and exposure, and photograph the trial checks.
Step 6: Keep joints clear and protect the fresh floor
Clean adhesive from the joint space to the depth required by the grout system. Keep movement joints free of rigid mortar and grout. Protect the surface from other trades and delay grouting, walking and loading until the specified cure stages have been reached.
For a heated floor, record the screed commissioning and restart sequence before installation. Use the underfloor-heating guide to coordinate the heating system, floor build-up and installation schedule.
4. Install Sintered Stone Countertops and Islands
Complete cabinet installation and levelling before the final template. The drawing should show the finished edges, seams, sink and hob models, appliance clearances, wall relief, rails and overhang supports. A last-minute change to a sink can change both the cutout and the support needed beneath it.
- Template and approve the layout. Check access, vein direction, opening positions and seam support against the actual cabinetry.
- Fabricate the openings with rounded internal corners. Use the current slab and machine instructions; inspect cut edges and corners before transport.
- Prepare continuous, level bearing where the design requires it. Fit the specified rails or frame at seams, appliance voids and overhangs. Install an independent support for an undermount sink.
- Dry-fit without forcing the slab. Check that seams meet, openings align and wall clearances remain. Correct the base or fabricated part if it rocks or binds.
- Bond, join and seal with the specified products. Follow the countertop assembly’s adhesive locations and joint detail; floor-style notched mortar is not automatically the right cabinet-bonding method.
- Protect and inspect before service. Keep construction loads off the top while adhesives and sealants cure, then check the sink support and every exposed edge.


| Check | Funtek manual reference | Application boundary |
|---|---|---|
| Internal corner radius | 12 mm slab: R8 mm minimum; R10 mm preferred | Match the opening drawing and fabrication method; larger radii reduce corner stress |
| Cutout to finished edge | 70 mm minimum; 100 mm preferred | Large openings, nearby seams and transport conditions may require a revised layout |
| 12 mm overhang | Up to 100 mm without added reinforcement; up to 150 mm with reinforcement | Uniformly supported, level cabinetry and normal residential loading; larger projections need a reviewed bracket or frame plan |
| Undermount sink | Independent mechanical cradle or rails | The slab and adhesive alone must not carry the filled sink and attached equipment |
These figures come from the current Funtek manual linked above. Check its complete support-spacing and loading conditions before cutting. For slab selection and project supply, see sintered stone countertops and kitchen islands.
5. Install Wall Panels and Shower Cladding
Check the capacity and condition of the complete wall assembly: framing, fasteners, board or render, waterproofing, adhesive, backing and slab. A clean wall surface alone does not establish that it can carry a large panel.
Dry-fit the wall layout around corners, taps, sockets and access panels. In a shower, complete the specified waterproofing, sealed penetrations and any required water test before covering the wall. The slab face and grout joints do not replace the waterproof layer behind them.

Apply the approved full-bed method, position the panel with lifting equipment, and use the specified temporary support while the adhesive cures. Keep corners and changes of plane available for the designed movement detail. Do not rely on small adhesive blobs to carry a large panel.
The large-format wall installation guide covers wall-specific preparation, handling and fixing choices in more detail. For an exterior facade, use an approved facade assembly: storey count alone does not determine whether adhesive bonding or mechanical fixing is acceptable.
6. Choose the Outdoor Paving or Facade Method
Outdoor work adds rain, drainage, temperature movement and, on raised or vertical systems, wind and restraint requirements. Select the complete assembly before ordering the slabs.
| Method | Installation checks | Detailed next step |
|---|---|---|
| Bonded exterior paving | Base, drainage falls, waterproofing where needed, exterior-compatible bonding, contact and movement joints | Resolve water paths and movement before laying |
| Dry-laid paving | Paver approved for the use, prepared sub-base, bedding, edge restraint and drainage | Review the sand and gravel paver installation guide |
| Raised pedestal deck | Approved paver size/thickness, pedestal layout, edge restraint, impact protection, loading and wind uplift | Obtain the pedestal and slab supplier’s accepted layout; self-weight alone is not a restraint design |
| Exterior facade | Load path through panels, anchors, rails, brackets and building structure; weather and movement details | Use the facade installation guide and project engineer’s drawings
Review the exterior facade panel and supply scope before selecting the final cladding assembly. |
A vehicle route needs a traffic-rated pavement design. An occupied raised terrace needs an approved supported system. Neither can be approved from slab thickness alone.
7. Finish Joints and Allow the System to Cure
A grout joint separates adjacent slabs. A movement joint allows parts of the assembly to move and uses the specified flexible sealant or movement profile. Filling both with rigid grout defeats the movement detail.

As named examples, Laminam recommends at least 2 mm between its indoor flooring slabs, subject to format and layout. Funtek’s countertop manual recommends 2–3 mm between finished parts and 3–5 mm relief at walls and fixed elements. These are different applications; floor perimeter and structural movement joints must follow the approved floor design.
Record separate times for grouting, light foot traffic, water exposure and full service. LATICRETE TDS 170F gives 72 hours before grouting and light foot traffic, and at least seven days of protection from heavy traffic, at 21°C for its described gauged-panel floor system. Temperature, substrate, slab size and the selected products can change the schedule. Use the requirements for the actual assembly.
Remove adhesive and grout residue within each product’s cleaning window using a method compatible with the finish. Check the care instructions before using a haze remover, solvent or abrasive pad. Surface sealer, grout treatment and flexible joint sealant perform different jobs; do not automatically apply a natural-stone sealer to the sintered slab.
8. Inspect the Installation Before Handover
Inspect in normal use lighting and keep photographs of the concealed work. A useful handover record includes the slab identity, adhesive and grout products, substrate checks, contact trials, support details, joint layout, installation date and permitted return-to-service times.
| Observed issue | What to investigate | Action before acceptance |
|---|---|---|
| Uncollapsed ridges or bare areas during a lift check | Open time, trowel choice, back-buttering and bedding method | Correct the method and reset while the system is workable |
| Raised slab edge or uneven joints | Base flatness, bed thickness, slab condition and forced levelling | Check against the agreed lippage tolerance; do not grind a finished face without approval |
| Crack starting at a cutout or seam | Corner geometry, transport damage, local bearing and nearby loads | Have the fabricator assess the cause and repair or replacement scope |
| Hollow sound after curing | Installation records, membrane or substrate acoustics, cracking and movement | Ask the installer to assess it; sound alone does not establish the extent of a bond failure |
| Rigid filler at a movement joint | Whether mortar or grout bridges the designed movement space | Restore the specified joint detail before it is concealed |
| Sink or free edge without the drawn support | Cradle, rails, brackets and their attachment to the supporting construction | Complete the support before loading or connecting equipment |
For a worktop, continue with the countertop handover checklist. Keep the accepted drawing and product records so later drilling, appliance changes or repairs can be assessed against the installed assembly.
Send Your Slab and Installation Details
Share the application, slab size and thickness, substrate, cutouts and project location with Funtek to discuss slab supply and fabrication requirements.
